Vertical sand Pump

PNSL vertical sludge pump is upgraded and developed by our company on the basis of like products at home. The improved PNSL pump has high efficiency, good overflowing condition, abrasion resistance and long service life, and is widely applied to cleaning up and filling sludge in lake and river.

The pump can be combined with high-pressure clean water pump to form a hydraulically excavating and filling machine set for dredging and filling operations. In addition, it can also combined in series with several vertical pumps and a marine-land purpose horizontal sludge pump to form an operation group.

Model Implication:

Structural Property:

pump consists of a pump body, an impeller, a guard plate, a motor frame, a bearing assembly and other parts
shaft gland of the pump is sealed by rubber framework oil seals.
3. The rotation direction of the pump is anticlockwise judging from the direction of impeller inlet.
associate impeller is adopted to reduce the back pressure of the impeller and prolong the service life of sealing elements.
overflowing part adopts white wear-resistant cast iron to resist abrasion.
