Vacuum Multipurpose Tile Making Machine

Technique Parameter1. Spindle Speed 30--40r/min 2. Host Power160C---7.5KW 160H 160H5---15KW 200---22KW3. Vacuum Pump PowerSB-A----3KW(suit to 160C)SB-B----4KW(suit to 160H and 160H5)2X-4----550W(suit to 160C)2X-8B--750KW(suit to 160H and 160H5)2X-15---1500KW(suit to 200) 4. Vacuum Degree: ≥0.09Mpa

Production	Specs	350 Type	200 Type	160H5 Type	160HType	160CType	Unit
Plain tile	190×190×8	90000	50000	29000	29000	12000	piece
Drip tile	190×190×8	----	----	15000	15000	6000	piece
No tenon pantile	110×8×180	----	----	25000	25000	11000	piece
Tenon pantile	110×8×180	----	----	16000	16000	10000	piece
Eave tile	110×8×180	----	----	16000	16000	5000	piece
Three bent tile	160×160×8	----	80000	43000	43000	2000	piece
Drip tile	160×160×8	----	20000	20000	10000	10000	piece
Sluice dam	160×8	----	----	160000	160000	80000	piece
6 inch tile	220×8	----	15000	7200	7200	2000	piece
S shape tile	220×220×10	----	----	7000	7000	2000	piece
S shape driping tile	220×220×10	----	----	5000	5000	1000	piece
S shape tile	280×280×10	----	----	5000	5000	1300	piece
S shapedriping tile	280×280×10	----	----	4000	4000	900	piece
Flat tile	220×14×330	20000	18000	15000	15000	4000	piece
Squre water pipe	60×80×8	----	----	14000	14000	9000	piece
Air brick	240×190×40	----	6000	3000	3000	1000	piece
Stove core	Φ 120×120	----	----	8000	8000	4000	piece
Wind brick	240×120×55	----	----	10000	10000	5000	piece
Pug mill	----	----	25000	12000	12000	5000
