VIP65 vandalproof stainless steel ATM EPP

DESCRIPTION:16 keys IP65 vandal-proof stainless steel encryption PINPAD with encryption module supporting DES/TDES is suitable for ATM/CDM, all kinds of bank terminals etc, with carbon-on-gold key switch technology with long stroke 2.0mm, with top panel mounting solution.

MODEL NO.: X-EP161F

DIMENSIONS: 120.0mm x 98.0mm(front panel)

APPLICATION

This encryption PINPAD is mainly targeted for use for unsupervised or semi-supervised positions of varied bank access applications, Bank kiosks, ATM, CDMs etc.

MAIN FEATURE

1.Stainless steel fascia and key-tops guard willful destruction, against corrosion, shock, dust, falling raining, splashing, hose-directed water and vandal resistant, operation under hostile environments.

2.Internet friendly key layout, key-tops are sunk laser-etched in legends and characters via using high quality ink for easy readability, long life to prevent lettering rub-off. Or protrusive engraving available.

3.The PINPAD in 4 x 4 matrix with Enter, Cancel, Correction, etc. compliance with ISO standard.

4.16 bytes keys (16 master keys x 4 working keys), it can be self destructive with back-up battery to achieve this function.

5.The PINPAD can be used as a keypad for numeric entry.

6.The ATM can instruct PINPAD to exit key entry/supervisory mode.

COMMUNICATION PARAMETER.

1.Standard RS232 serial interface.

2.Communication velocity: 19200, 9600, 4800, 2400, 1200bps.

3.Data format: N, 8, 1.

4.16 actuators: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, correct, enter, cancel, backup key 3 defined for ABC.

5.Data encryption and decryption (DES/TDES), MAC Algorithm.

6.Encryption rate: < 1 second.

MECHANICAL DATA

1.Key: 16 keys, SUS304 brushed stainless steel

2.Key top style: Protuberant rectangular keys, with laser engraved and etched legends and raised braille on keys are available

3.Key travel: 2.0mm

4.Front Plate: Super quality brushed stainless steel

5.Actuator/keys materials: stainless steel

6.G.W.: 1.0KGs (X-EP161F)

ELECTRICAL DATA

1.Power supply voltage: 5V DC.

2.Power Consumption: Under 30mA for operation

3.Communication interface: RS232.

ENVIRONMENTAL ADAPTABILITY

1.Operating temperature:-20C to +60C.

2.Storage temperature: -30C to +70C.

3.Operating RH: 30-90%.

4.Atmospheric pressure: 60-106Kpa.

RELIABILITY

1. RoHS Compliant, CE and FCC

2.Protection Level: IP65(front panel static)

3.Vandal resistant IK10

4.MTBF >50000H.

5.MTTR <30min.
