Universal Testing Machine (Computer Controlled Electronic-Hydraulic Servo)
Specifications
- Origin
- China
Universal Testing Machine (Computer Controlled Electronic-Hydraulic Servo) is a Health & Medical product. Key specs — Origin: China.
Product Description
This series machines Universal Testing Machine (Computer Controlled Electronic-Hydraulic Servo) are widely used for tension, ompression, bending and shearing test of metal materials and also used for compression and bending test of nonmetal materials, such as cement, concrete and so on. Equipped with simple auxiliaries, it can be used for mechanical property testing of fastener, wire rope and components.
They are perfect testing instrument project quality testing section, universities and colleges, research institution and industrial and mining enterprise. The machine is designed and made according to ISO7500, ASTM A370, ASTM E4, ASTM E8 and BSEN standards.
| Model | WAW-100 | WAW-300 | WAW-600 | WAW-1000 | ||
| Maximum force(KN) | 100 | 300 | 600 | 1000 | ||
| Measuring range of force(KN) | 2%-100% ; no subsection (or 4 subsection according to the requirements of customer ) | |||||
| Accuracy | ±1% of indicated value | |||||
| Resolution of displacement measure | 0.01mm | |||||
| Accuracy of deformation measure | ±0.5%F.S | |||||
| Control range of stress speed | 1-60MPa/S | |||||
| Speed adjusting range of testing stress | 1N/mm2S-1-60N/mm2S | |||||
| Speed adjusting range of testing strain | 0.00025/S-0.0025/S | |||||
| Control range of displacement speed | 0.5mm/min-50mm/min | |||||
| Clamping diameter for round specimen (mm) | φ6-φ22 | φ10-φ32 | φ13-φ40 | φ13-φ60 | ||
| Clamping thickness of flat specimen (mm) | 0-15 | 0-15 | 0-30 | 0-40 | ||
| Clamping width of flat specimen (mm) | 40 | 70 | 70 | 120 | ||
| Testing space | Tension (mm) | 550 | 750 | 800 | 650 | |
| Compression (mm) | 500 | 650 | 700 | 600 | ||
| Platen size | φ100 | φ130 | φ180 | 210 x210 | ||
| Distance of bending by pass roll (mm) | 30 -400mm | 30--580 mm | 30-580 mm | 30 -800 mm | ||
| Maximum piston stroke (mm) | 250 | |||||
| Working environment | Room temperature 10- 30, relative humidity≤80% | |||||
| Overall dimension (mm) | Host machine | 720×560×1860 | 905×580×2260 | 905×580×2325 | 1070×850×2530 | |
| Control cubicle | 600×600×1165 | 600×600×1165 | 600×600×1165 | 600×600×1165 | ||
| Weight (kg) | 1350 | 2700 | 3000 | 4100 | ||
