Universal Pressure Transmitter supply

Multi-structure, material safety, oil proof, high performance of stability and reliability, multi-output forms, a wide measurement range, high stability and reliability, wide range of power supply and output. Protection of reversed circuit,high stability,stainless steel.

CS-PT300E can be specially used in some flammable environment. l Technology Data Measurement Range: 0 to 200 kpa …… 0 to 100Mpa Accuracy: 0.5% F.S, 0.2% F.S ( including linearity, repeatability and hysteresis) Output: 4~20mA, 1~5V,0~5V,1~10V,0~10V Power supply: 12VDC~36 VDC Pressure Connection: M20X1.5(others on request) Response Time: 10ms Allowed over pressure: 2.5 times full scale Pressure form: Gauge Long Term Stability: ±0.15% F.S per year Compensated Temperature: from -10℃ to +60 ℃ Working Temperature:-40℃ to +85 ℃ l Application It can be used in measuring pressure of aerospace equipment, industry process control, hydraulic pressure controlling system, water treatment, food and drink mechanical instrument and thermodynamic system.
