Ultrasonic liquid level meters
Listing ID#10137200
CategoryIndustrial Power Supplies
Industrial Power Supplies

Ultrasonic liquid level meters

Specifications

Origin
China (Mainland)
Price Term
FOB
Request Quote
Quick answer

Ultrasonic liquid level meters is a Industrial Power Supplies product. Key specs — Origin: China (Mainland); Price Term: FOB.

Product Description

TECHNOLOGICAL SPECIFICATION ： RANGE ： HLT4：4.00m（Liquid） HLT6：6.00m HLT8：8.00m BLANKING DISTANCE ： HLT4：0.20m HLT6：0.25m HLT8：0.30m Accuracy （ In air ） ： 0.2%Full Span Output Current ： 4~20mA Output Load ： 0~500Ω Output Resolution Ratio ： 0.03% full span Parameter Set Up ： 3 induction buttons Temperature Range : -40ºC~80ºC Temperature Compensation : The whole range is automatic Pressure Range : ±0.1MP (press definitely) Power Supply: DC24V ±20% 30mA Cable

Diameter: F6~F12mm Single Wire

Diameter: F0.5~F1.78mm Cable Fix ： PG13.5 Beam Angle ： 8º(3db) Measuring Range 4m 6m 8m 5º(3db) Measuring Range 8m(A) 10m 15m 20m 30m Measure Cycle ： 1 second Crust

Material : ABS Sensor Material ： PVC Protect Grade: IP67 Mode Installation: Flange or the support Fange Standard of Butt Joint: Measuring range 4m 6m 8m:Minimum DN65
