ULTRASONIC THICKNESS GAUGE ST-083CHY

Application

Used for measuring thickness and corrosion of pressure vessels, chemical equipment, boilers, oil storage tanks, etc. In industries of petroleum, shipbuilding, power station, and machine manufacturing.

Technology parameter

Model

ST-083CHY

Operating principle

Ultrosonic

Measure range

1.2~200mm(45# steel)

Sound velocity

500~9000m/s

Lower limit steel pipes

φ15*2.0mm, φ20*3.0mm determined by the transducer

Calibration block

Included

Resolution

0.1mm

Accuracy

±0.5%n±0.1

Power

DC9V×1

Environment temperature

0~40

Relative humidity

≤85%

Dimension

125mm×74mm×33mm

Weight(Not including battery)

180g

Materials measured

Any hard materials, including steel, Cast iron, Aluminum, Red copper, Brass, Zinc, Quartz glass, Polyethylene, PVC, Gray cast iron, Nodular cast iron and other materials.

Standard Delivery

Main unjit 5Mφ10 transducer Couplant Instruction manual Carring case
