Tandem Diaphragm Valves

The most common customised valve concept is the tandem valve or valve and fitting combination. A main valve is ported and a section of tube is welded to the port to create an access point into the valve. This tube can in turn be welded to a second valve forming a two-valve cluster, or the tube can be turned into a weld end, hygienic clamp or other type of fitting. The resultant product is designed to optimise drainability and meets standard process considerations including camps for dead leg minimisation.

Size Range: DN6-DN100 (¼ 4)

End Connections: Tri-clamp or Butt-weld end connections

Body Material: US316L

Diaphragm Material: EPDM or EPDM+PTFE

Body Configuration: 2way, L pattern, T pattern, Multiway, Tandem, Tank Bottom

Surface Finish: Mirror polishing treatment

Standard: ISO, DIN, IDF, SMS

Operation: Manual or Pneumatic

Application: pharmacy, beer, food, dairy, beverage, cosmetic, chemical industry

We can offer all kinds of the Diaphragm valves according to your drawings.
