Sump Pumps EVM Series

is a professional slurry pump manufacturer in China. With the accumulation and development of years, we have formed a complete system of slurry pump design, selection, application and maintenance.

Introduction

This sump pump casing of type EVM pumps are made of wear-resistant metal. The wear parts are made of high chromium for the EVM series and are rubber lined for the EVMR series. According to liquid surface of the slurry pool, the vertical slurry pump transmission shaft and suction pipe could be chosen. The sump pump could operate under the best condition with different speed.

Application

The vertical slurry pumps are designed for delivering abrasive, large particle and high-density slurries and applied over the fields such as metallurgy, mining, coal, power, building materials, and environmental protection .

Model Explanation and Performance Chart

EVM-65Q

E: Excellence Brand

V: Vertical

M: Metal lined

65: Discharge size (mm)

Q:Frame type with maximum power
