Steel Rolling Mill

Steel Rolling Mill

Our steel rolling mill can be used to produce a variety of structural sections, such as deformed steel bar, angle steel, square steel, flat bar, channel steel, and profiled bar, and so on.

Our steel rolling mill is a kind of completely continuous high speed wire rod mill. The overall technical solution of the automated and adjustable speed drive system is to take high performance industrial PC, PLC and full digital AC-DC drive control system as the core and make up an entire distributed network.

The whole automated system is composed of second-level control system, three layer communication network, full digital AC and DC drive speed governing controller.

Technical Parameters of Steel Rolling Mill:
nbsp

Item		Unit	Technical parameters
			FF300×4	FP250×6	FP250×2	FP220×2
Diameter of roll		mm	Φ280-Φ330	Φ230-Φ280	Φ230-Φ280	Φ200-Φ240
Working face length		mm	700	500	500	350
Main motor	Power	KW	500	500	240	185
	Rotate speed	FPm	590	590	738	738
Distribution box	Modulus	mn	12	10	10	8
	Center distance	mm	1350	1250	1250	1200
	Width of gear	mm	615	500	450	400
Gear box	Modulus	mn	12	10	10	8
	Center distance	mm	310	260	260	220
	Width of gear	mm	604	550	450	500
Rotating way			Universal coupling shaft	Universal coupling shaft	Universal coupling shaft	Universal coupling shaft
Weight of machine series		T	68.16	72.13	17.7	12.3

As a professional steel rolling mill manufacturer in China, we can provide not only steel rolling mills, but also impact crushers, pendulum feeders, coal gasifiers, cooling machines, disc granulators, etc. They are of high quality and low price, and are convenient to use.
Located in Shanghai, we are near to highways, airports and deepwater docks. This will help reduce your transportation cost.
Welcome customers all over the globe to contact us!
