Stainless steel immersion heater

vertical stainless steel heater

industrial electric heater

liquid electric heater

Immersion electric heater

Guarantee 100%

vertical stainless steel heater

Features:

1. The products are made by titanium, zirconium, SUS304, SUS316 stainless steel tube, with the shape classified into L shape and Z shape.
2. 2. Power of the heating tube is designed according to the location of installation, liquid chemical properties and the deposition of the solid-like contents in liquid in order to insure diameter of the tube, the normal specification are 11mm, 16mm, 19mm, 25mm, 38mm, 45mm and 50mm.
3. Tubes of 11mm and 16mm are heat-shrinkable, its surface power is about 5-10W/Cm2, which is applicable to heat in the liquid with good liquidity and little solid deposition.
4. Tubes of 45mm are designed with low surface power, with good durability, which specially applies to circuit board.
5. With voltage of110V/P,220V/P,380V/P,220V/3P,380V/3P,415V/3P and power range from 0.5KW to 50KW.
6. All heaters can be used with overheat protection switches or Heat detector.
7. All heaters reach the international standard, which insure the reliability and service life.
