Listing ID#10059877
ModelG-277
CategoryFasteners
Stainless Steel Short Shoulder Nut G-277
Specifications
- Brand
- wanlong
- Origin
- China
- Price Term
- FOB
Quick answer
Stainless Steel Short Shoulder Nut G-277 is a Fasteners product. Key specs — Brand: wanlong; Origin: China; Price Term: FOB.
Product Description
Features Specifications of Shoulder Nut,G-277
Material of Shoulder Nut:stainless steel 304, 316
Size of Shoulder Nut1/4*1" to 1*21/2"
Applications of Shoulder Nut: eye bolt,eye screw,fastener,rigging hardware
Material of Shoulder Nut:stainless steel 304, 316
Size of Shoulder Nut1/4*1" to 1*21/2"
Applications of Shoulder Nut: eye bolt,eye screw,fastener,rigging hardware
| ART.NO. | Dimensionin.) | W.L.L | |||||
| SIZE | A | B | C | D | Thread | Lbs | |
| XY04-0706 | 1/4"x 2" | 1/4" | 1.50" | 2.00" | 0.51" | 1 1/2 | 500 |
| XY04-0707 | 1/4" x 4" | 1/4" | 2.25" | 4.00" | 0.51" | 2 1/2 | 500 |
| XY04-0708 | 5/16" x 2-1/4" | 5/16" | 1.50" | 2.25" | 0.63" | 1 1/2 | 800 |
| XY04-0709 | 5/16"x 4-1/4" | 5/16" | 2.50" | 4.25" | 0.63" | 2 1/2 | 800 |
| XY04-0710 | 3/8"x 2-1/2" | 3/8" | 1.25" | 2.50" | 0.75" | 1 1/2 | 1200 |
| XY04-0711 | 1/2"x 3-1/4" | 1/2" | 1.50" | 3.25" | 1.02" | 2 1/2 | 2150 |
| XY04-0712 | 1/2"x 6" | 1/2" | 3.00" | 6.00" | 1.02" | 23 | 2150 |
| XY04-0713 | 5/8"x 4" | 5/8" | 2.00" | 4.00" | 1.25" | 2 | 3440 |
| XY04-0714 | 5/8"x 6" | 5/8" | 3.00" | 6.00" | 1.25" | 3 | 3440 |
| XY04-0715 | 3/4"x 6" | 3/4" | 3.00" | 6.00" | 1.52" | 3 | 5140 |
| XY04-0716 | 7/8"x 5" | 7/8" | 2.5 | 5.00" | 2 | 2 1/2 | 7130 |
| XY04-0717 | 1"x 6" | 1" | 4.00" | 6.00" | 1.75" | 3 | 9370 |
Our company is specialized in producing series of stainless steel rigging hardware mainly used in the ships and vessels ,such as turnbuckles, shackles, wire rope clips, swivels, U bolts, S hooks, spring hooks, pad eyes, eye bolts, you are interested in the items, please feel free to tell me.
