.Spray bottle—washing machine

1. Technology specification Model CX-18 CX-12 Production capacity 3000-6000 b/h 2000-4000 b/h Bottle neck Ф50-ф100mm Ф50-ф100mm Bottle height 160-320mm 160-320mm Mainframe power 0.75kw 0.75kw Outer size 1600×1500×1700（mm） 1200×1100×1700(mm) Machine weight 1200kg 800kg 2.

Technology parameter Washing medium Sterile water Washing time 3s Drying time 2s Water pressure 0.2Mpa-0.4Mpa 3.

Operation principle Conveyor belt will put needed cleaning bottles into the bottle screw , due to the bottle inputting screw and star wheel catch plate are continuously operating in-phase which will synchronously convey the needed cleaning bottles to the center transferring manipulator , and the manipulator along with the rotary table are spraying and washing the needed cleaning bottles , it will revert into the start-off state after compeleted , then the bottle outputting star wheel catch plate makes the cleaned bottle out , so the whole process is completed .
