Spectra Skywalker Nano Heavy-Duty Solvent Printer
Specifications
- Origin
- China
Spectra Skywalker Nano Heavy-Duty Solvent Printer is a Printing Machine product. Key specs — Origin: China.
Product Description
Skywalker Nano Heavy-Duty Solvent Printer 1) Adopted world famous American SPECTRA SKYWALKER-50 PL Printhead with all stainless steel nozzle plate, using life 7-10 years; Imported negative pressure system and supreme print head performance ensured the constant printing for 3 hours without jamming on conditions of no cleaning during printing. 2) Fire frequency is 16K Hz, high productivity of 120sqm/H by 2 Pass with vivid color presentation. 3)Imported AC Servo Motors and Reducers equipped X and Y axis movement systems 4)THK linear rail made in Japan, Megadyne timing belt made in Italy, Auto media width sensor. 5)Quartic ink filtrations for each color ink through American PALL filters. 6)Digital Ink Constant Temperature System reduced the cost that caused by environment temperature changing. 7)High precision mechanism processing exceeded the Industry Standard.
| Model No. | Skywalker Nano Heavy-Duty Solvent Printer | |
| Printhead | Type | Spectra Skywalker 128 printhead |
| Quantity | 4 / 8 pcs | |
| Max Printing Width | 3200mm | |
| Resolution (dpi) | 1440dpi maximum | |
| Color | 4 color | |
| Speed | Draft | 59.5 sqm/h |
| Standard | 43.7 sqm/h | |
| High quality | 21.3 sqm/h | |
| Media | Width | 3.2 meters |
| Types | Frontlit, Backlit, Vinyl, Polyester, Window Film, Mesh, Leather, Backlit Film | |
| Ink Type | Solvent Ink | |
| Feeding and Take-up | Automatic Media Feeding & Take-up System < 70kg / roll | |
| Cleaning System | Positive Pressure Cleaning,Anti-Clogging Flash Function & Capping System | |
| Printhead Height | 2mm-4mm above media adjustable | |
| Media Heater & Drier | Pre, Middle & Post heaters, 40-55C adjustable. Fans Drier (Opt.) | |
| Environment | Temperature: 20C-28C, Humidity: 40%-70% | |
| Rip Software | Aprint Rip, Onyx, Scanvec, Wasatch Rip supported | |
| Printhead Height | 2-4mm (adjustable) | |
| Interface | USB 2.0 | |
| Operation System | Windows2000, XP, Vista | |
| Power | AC 100-240V, 50HZ/60HZ, Print: ≤3A, Heating: ≤5A | |
| Size Weight | Machine | L4,600mm x W860mm x H1100mm / 340kg |
| Packing | L4,828mm x W906mm x H1115mm / 380kg | |
