Sound Level Meter(grade 2)
Specifications
- Brand
- Midwest Group
- Origin
- China (Mainland)
Sound Level Meter(grade 2) is a Auto Meter product. Key specs — Brand: Midwest Group; Origin: China (Mainland).
Product Description
Sound Level Meter(grade 2) Model:ZH1/AWA5633P Cat.No:W35540
Speciations PERFORMANCE SPECIFICATIONS Measuring Range: 40 dB ~ 130 dB(re.20 µPa) Frequency Weighting: A Frequency Response: 20 Hz ~ 8 kHz Time Weighting: F, S Meas. Functions: Lp, Lmax Standard: IEC 61672-1 :2002 Class 2 INPUT Microphone: 1/2" Prepolarized Condense Mic.
ZH1/AWA14421 Sensitivity: 40 mV/Pa Reference Direction: Axial direction of microphone OUTPUT Indicator: 4 digital (LCD) with signs of overload and battery low POWER SUPPLY Battery: 2 × LR03 batteries Operating Voltage: 3 V DC Battery Life: Approx.
20 hours Operating Current: 20 mA ENVIRONMENTAL Temperature: 0°C ~ +40°C Humidity: 25% ~ 90% (R.H) Atmospheric Pressure: 65 kPa~108 kPa PHYSICAL Dimension(L×W×H): 130 × 40 × 16 mm Weight: < 80g (including batteries) ACCESSORIES Included: 1/2" Prepolarized Condense Mic.
ZH1/AWA14421 × 1 Windscreen F35mm × 60 mm × 1 Battery LR03 × 2 Instruction Manual x 1 Available: Sound Level Calibrator ZH1/AWA6221 (Class 1) Sound Level Calibrator JH811/AWA6221B (Class 2) Purpose:Research Classified:Physics nbsp; Sound Level Meter(grade 2) Model:ZH1/AWA5633P
