Solvent Printer (Skywalker Nano Light-Duty)

Solvent Printer 1) Adopted world famous American SPECTRA SKYWALKER-50 PL Printhead with all stainless steel nozzle plate, using life 7-10 years; Imported negative pressure system and supreme print head performance ensured the constant printing for 3 hours without jamming on conditions of no cleaning during printing.

2) Fire frequency is 16K HZ, high productivity of 120㎡/H by 2 Pass with vivid color presentation. 3)Imported AC Servo Motors and Reducers equipped X and Y axis movement systems 4)THK linear rail made in Japan, Megadyne timing belt made in Italy, Auto media width sensor. 5)Quartic ink filtrations for each color ink through American PALL filters.

6)Digital Ink Constant Temperature System reduced the cost that caused by environment temperature changing. 7)High precision mechanism processing exceeded the Industry Standard. Model No.

Spectra Skywalker Nano(Light-Duty) Printhead Type Spectra Skywalker 128 printhead Quantity 4 / 8 pcs Max Printing Width 3200mm Resolution (dpi) 1440dpi maximum Color 4 color Speed Draft 59.5 sqm/h Standard 43.7 sqm/h High quality 21.3 sqm/h Media Width 3.2 meters Types Frontlit, Backlit, Vinyl, Polyester, Window Film, Mesh, Leather, Backlit Film Ink Type Solvent Ink Feeding and Take-up Automatic Media Feeding & Take-up System < 70kg / roll Cleaning System Positive Pressure Cleaning,Anti-Clogging Flash Function & Capping System Printhead Height 2mm-4mm above media adjustable Media Heater & Drier Pre, Middle & Post heaters, 40-55C adjustable.

Fans Drier (Opt.) Environment Temperature: 20C-28C, Humidity: 40%-70% Rip Software Aprint Rip, Onyx, Scanvec, Wasatch Rip supported Printhead Height 2-4mm (adjustable) Interface USB 2.0 Operation System Windows2000, XP, Vista Power AC 100-240V, 50HZ/60HZ, Print: ≤3A, Heating: ≤5A Size Weight Machine L4,600mm x W860mm x H1100mm / 340kg Packing L4,828mm x W906mm x H1115mm / 380kg
