Specifications

Brand: HIMIN
Origin: China
Price Term: FOB

Product Description

Features: • Product name: solar panel / solar module • Solar cell: Monocrystalline silicon solar cells, 125mm square. • number of cells and connections: 72 in series • Construction: low-iron tempered glass-EVA resin-solar cells-EVA-TPT-aluminum frame •

Application: DC 24V system • Maximum system voltage: DC1000V • Series fuse rating: 10A • Normal power: 185-200w •

Dimensions: 1580*808*50mm •

Weight: 16.2KG • Type of output terminal: Lead wire with connector • Life time: 25 years

Terms: • 30TT% in advance or 100% L/C at sight
