Solar Module Features
Specifications
- Brand
- zhejiang wanbao
- Origin
- zhejiang china
- Price Term
- FOB
Solar Module Features is a Solar Panels product. Key specs — Brand: zhejiang wanbao; Origin: zhejiang china; Price Term: FOB.
Product Description
Solar Module Features1. The module is designed in consistent with IEC 1215:1993 standards, manufactured with proven materials and tested to ensure the stable output power and more than25year-guarantee of service performance.2. For each 18 and 36 cells series strings, one bypass diode is installed to avoid “hot spot” effect.3.
SiN/TiO2 films deposited on the front surface by PECVD acts as anti-reflection coating and give a uniform dark blue appearance.4. Cells are laminated between high transparence lowiron 3mm tempered glass and sheet of TPT material by two sheets of EVA to prevent moisture penetrating into the module.5.
Heavy duty anodized aluminum frame provides high wind resistance and convenient mounting access.6. A water-proof versatile junction box provides flexibility of connection.7. Each piece of module passes the strict appearance check and performance test which guarantee the high quality level.
