Small character Ink Jet Printer

Introduction:StructureStainless steel shell, IP55 protection standard, resistance to dust invasion. Can be applied in different working environment. The ink system and circuit control system are separated to avoid influence to each other.

Most Advanced Design of Ink SystemIt is able to accomplish groups of automatic ink handling work in way similar to zero boasts the following advantageslong service life,low maintenance cost,low ink degradation,which prolongs service life of ink Advanced Auto Control System of Ink ViscosityIt adopts advanced auto control system of ink viscosity which is free from the influence of factors, such as ambient temperature and startup time, and guarantee the printing quality of ink jet printer.

Viscosity control is realized through inspection of time of float motion. Compared with ink jet printers of other brands that adopt inspection of dropping time, it is more accurate and more reliable.

Perfect interfacePinyin and English input.built-in Chinese character library, big LCD screen, direct lattice editing for jet, synchronous editing and printing,easy operation and storage of a number of messages. 500 can store information.Three lines jet printing and anti-fake design. Flexible choice of lines and rows.

More pleasant font and more powerful function.

Unique Ink Jet Printingsynchronous photoelectricity.synchronous distance of synchronizer, online inspection of printing of N times Saving suppliesOptimized design of ink system, ink path with small size fount, small diameter pipe, and low ink operation pressure lowers the flux and stirring of flow in the pipe and controls effectively the volatilization of solvent.

Technical Parameters ● Font lattice  5×7,7×9,8×8,8×12,12×12,16×8,16×16,16×24,24×24● Printing lines      1-3 lines can be adjusted ● Font height      1.2-15MM can be adjusted ● Printing speed      5m/s (single line 7×6 )● Printing direction    All round adjustment ● Printing content    Chinese characters, English letters, Arabic numerals, pictures and literatures ● Printing format     Production date ,Different layout of batch number of product, serial number, total amount, Chinese and English, picture and literature, auto continuous printing, delay printing, positive direction, negative direction, and reverse printing● Pinyin and English input, Chinese characters library, direct lattice editing  ● Functions of synchronous coding, synchronous photoelectricity, synchronous distance of synchronizer, online inspection of printing of N times.● Power                    120W● Power supply           220V±10%VAC,50HZ● Ambient temperature         5-40℃● Ambient humidity          10%-90%RH(no dew condensation)● Dimension          620X260X440mm● Weight               16KG● Shell                Stainless steel
