Silicone glass cloth laminated sheet
Specifications
- Origin
- China (Mainland)
Silicone glass cloth laminated sheet is a Other Plastic & Rubber Machinery product. Key specs — Origin: China (Mainland).
Product Description
Product Name: Silicone glass cloth laminated sheet Model No: 3250 G7 Detailed Product Description: Silicone glass cloth laminated sheetSilicone glass cloth laminated sheet Type: 3250 (China standard) G7 (NEMA standard) It is created from electrical glass cloth with alkali-free that has been impregnated with silicone resin under pressure. heat and rolling.
With excellent mechanical strength and dielectric property, wet-resistant . Used for the insulating slots. windings. gaskets. junction board of the dry type transformer, railway transformer, electrical equipment, traction motor etc. Thermal grade is class H. Sheets: Thickness : 0.5-100mm; Size: 960x1960mm, 1000x2000mm
