Shore Durometer

is widely used to test common rubber, complex rubber, soft rubber,elastomers, leather, wax and so on. It complys with DIN 53505, ASTM D2240, ISO/R868, JIS R7215.Executive standart - GB/T531-99,GB2411-80, HG/T2489-93,JJG304-2003.

Specification:

lHigh Resolution

lWith facility, easy to operate

lUse by hand or by

lTest range: 0-100HA

lAvailable test range: 10-90HA

lStroke: 2.5 mm

lTip dimension: Φ0.79mm

lDimension: 115*60*25(mm)

lNet weight: 0.5kgs

Shore C Durometer is widely used in testing of various foam, sponge, microporous material and so on. It complys with HG/T2489-93.

Specification:

lHigh resolution

lWith facility, easy to operate

lUse by handy or by

lTest range: 0-100 HW

lAvailable test range: 10-90 HW

lDimension: 115*60*25(mm)

lStroke: 2.5 mm

lTip dimension: SR2.5mm

lNet weight: 0.5Kgs

Shore D is widely used to test hard rubber, hard colophony, grass, plastic,print board, fibre and so on. It complys with DIN 53505, ASTM D2240,ISO/R868, JIS R7215.executive standart - GB/T531-99, GB2411-80,HG/T2489-93, JJG304-2003.

Specification:

lHigh resolution

lWith facility, easy to operate

lUse by handy or by test stand(HLX-D)

lTest range: 0-100 HD

lAvailable test range: 10-90 HD

lDimension: 115*60*25(mm)

lStroke: 2.5 mm

lTip dimension: SR0.1mm

lNet weight: 0.5Kgs
