Sensor is a Sensors product. Key specs — Brand: Midwest Group; Origin: china.
Product Description
Product features Sensing range min ... max: 5 ... 400 mm Measuring condition: Scanned object with 90% remission (relative to standard white according to DIN 5033) Light source: LED Type of light: Infrared light Light spot size:approx. 20 mm at 400 mm distance Optical axis: axial
Technical data Design: Cylinder with thread Thread size: M18 x 1 Supply voltage min ... max: DC 10 ...
30 V Switching output: PNP Switching mode: Light-/dark-switching via L/D control cable Response time: <= 2 ms Switching frequency: 250 Hz Connection type: Cable, PVC, 2 m Enclosure rating: IP 67 Ambient operation temperature, min ... max: -25 °C ... +70 °C Housing material:Brass nickel-plated, plastic Optics material: PMMA
