SPL-9900 Super DVB Satellite Receiver

Demodulator type QPSK&FEC symbol rate 2-45Msps SCPC and MCPC capable Video/Audio decoder video decoder MPEG-2 main level Audio decoder MPEG-1 layer 1 and 2 Memory NTSC/PAL/SECAM Video output 720* pixel 720* video format 4:3 16:9 LNB/Tuner input(digital) input frequency 950 to 2150Mhz LNB supply 13/18V Max.600mA Band switch control 22KHz DiSEqC 1.0,1.2.USALs compatible connector 2*F-Type Polarizer connector push terminal 3pin voltage DC +5V TV SCart RGB,CVBS,Audio L/R VCR SCart CVBS,Audio L/R RF Modulator connector 750hm,IEC169-2,male/female output channel CH21-69,169-2 Data Service Port connector 9-pin D-sub Data protocol RS232C Data Rate Max.115,200 bits/s Power Supply Type switching mode power supply Input voltage AC 60V-285 50/60Hz Nominal power consumption Max.30W-FTA,CI Max,140W-DPCI
