SMD Crystal Oscillator is a Oscillators product. Key specs — Origin: China (Mainland).
Product Description
Model No.:VC-81, 83 series Product
Origin:China Brand
Name:LGE
Price Terms:FOB Shenzhen
Payment Terms:T/T in advance
Certification:ISO9001, ISO14001 Description:
Specifications: 1) Frequency range: 1.750MHz - 45.000MHz2) Frequency calibration at 25oC: +/-15ppm3) Temperature stability: +/-15ppm, +/-25ppm, +/-50ppm4) Pull ability: a) VC-S1: +/-50ppm, +/-100ppm, +/-200ppm b) VC-S3: +/-50ppm, +/-100ppm, +/-150ppm5) Control voltage range: a) VC-S1: 0.5 - 4.5Vb) VC-S3: 0 - 3.3V6) Operating temperature range: 0 - 70oC (-40 ~ +85oC option)7) Storage temperature range: -55 ~ +125oC8) Output load: 15PF max.9) Start-up: 10ms max.
