SCM Centrifugal Pump
Listing ID#10135920
CategoryPumps & Parts
Pumps & Parts

SCM Centrifugal Pump

Specifications

Brand
Jingtai
Origin
China (Mainland)
Request Quote
Quick answer

SCM Centrifugal Pump is a Pumps & Parts product. Key specs — Brand: Jingtai; Origin: China (Mainland).

Product Description

PERFORMANCE RANGE
flow rate up to 120 l/min.(7.2m3/h)
head up to 33 m

OPERATING LIMITS
suction lift up to 8m
fluid temperature up to 40℃
maximum ambient temperature 40℃
WARRANTY:1 YEAR(according to our general sales conditions)
PERFORMANCE CHART AT n=2900rpm

MODEL POWER(Kw) POWER(HP) INLET/OUTLET MAX.FLOW(L/min) MAX.HEAD(m) MAX.SUCT(m) GW(kg)
SCM-22 0.37 0.5 1"x1" 90 22 8 9.2
SCM-42 0.55 0.75 1"x1" 100 27 8 12
SCM-60 0.75 1 1"x1" 120 33 8 12.5

H=TOTAL HEAD IN METERS. Q=FLOW RATE
