Rubber Calender

1. The Rubber Calender Machine is mostly used in oppression of rubber products and textile (like cotton, rayon, nylon etc.). The precision calender besides has the ordinary calender main spare part and the equipment, increased the guarantee rolling precision installment.

2. We have three-roll, four-roll and two-roll calender, should any of items be of interest to you, please contact me for further details.

3. Rubber Calender Machine is according to certain form arrangement, under certain temperature, extends the rubber or the plastic suppression certain thickness and the superficial shape film.

Model

XY-2I1320 XY-2I1830 XY-2I1730 XY-3I1400 XY-3I1500 XY-3I2430 XY-4Г1120A XY-4Г1400 XY-4Г2430

Roll dia mm 160 550 230 450 610 230 400 450 810

Roll working length mm 320 1830 630 1500 1730 630 1400 1500 2430

Roll ratio 1:1 1:1.08 1:1:1

1:1.42:1 1:1:1

1:1.5:1 1:1:1

1:1.4:1 1:1:1:1 1:1.383:1.383:1 1:1.5:1.5:1 1:1.5:1.5:1

roll linear speed r/min 7.79 2-18.7 0.8-8 2.62-26.2 5.4-54 2.1-21 3-26.3 2.5-25 2-20

Adjusting nip range mm 0-4.5 0-12 0-7 0-6 0-20 0-10 0-10 0-6 0.5-25

Min. Calendering product thickness mm 0.2 0.2 0.2 0.2 0.15 0.2 0.2 0.2 ±0.1

Calendering product width kg 250 1600 100-500 1400 1400 100-500 1200 1250 2150

Motor power kw 5.5 75 7.5 75 132 15 75 110 280
