Rotating Cooling Conveyor
Specifications
- Brand
- DEREN
- Origin
- China
Quick answer
Rotating Cooling Conveyor is a Bath Brushes, Sponges & Scrubbers product. Key specs — Brand: DEREN; Origin: China.
Product Description
Cooling conveyer is an auxiliary machine of the Precision Preformer to avoid stickiness and deformation of the rubber blanks. According to the different ingredients of the rubber, the different shapes of the rubber blanks and the different requirements of other functions, we can choose different types of cooling conveyers, such as LSX rotating model, LSS water cooling model and LSF wind cooling model. With cooling water, cooling solution and forcible wind, the rubber blanks will become cool and solid.
Technical Parameter
Item/Model | LSX800 | LSX950 | LSX1150 |
Groove Diameter (Mm) | 800 | 950 | 1150 |
Groove Width (Mm) | 200 | 200 | 210 |
Groove Height(Mm) | 1500 | 1500 | 1800 |
Material Travel Distance (Mm) | 28000 | 35000 | 44000 |
Helical Pitch (Mm) | 100 | 100 | 120 |
Feeding Width (Mm) | 650 | 650 | 650 |
Height of inlet(Mm) | 320 | 320 | 320 |
Conveying Speed (M/min) | 6-8 | 6-8 | 6-8 |
Motor Power (W) | 750×2 | 750×2 | 1100×2 |
Overall Dimension (M) (L×W×H) | 1.4×2.0×2.5 | 1.6×2.2×2.5 | 1.8×2.4×2.7 |
