Reflective Pavement/Road Marking Tape

PL5000 reflective pavement marking tape is pre-made with synthetic rubber. It has high tensile strength with the surface coated with glass-beads that has good retro-reflectivity. With high performance coatings on the tape, it has a strong anti-friction, an ability of self-cleaning and non-stickiness to dust and mud.

The bottom is coated with a strong and weather resistant adhesive which improves the adhesion between road and tape, it makes the tape firmly stuck on roads.

PLYON reflective pavement marking tape has not only a good retro-reflectivity, but also has an easy application advantage than ordinary road signs.Features :Good retro-reflectivity all day long ; anti-skid ; high tensile ; strong weather resistance ; easy application .Application: It can be used for road signs ; letters; arrows; graphics; warnings at port, airport, toll, parking lot etc.ReflectanceTable # 1 illustrates PLYON PL5000 pavement marking tapes excellent minimum reflective properties.

Measurements made using ASTM Test Method D4061.Table # 1 Minimum Retroreflectivity Values White yellow

Entrance Angle 88.76° 88.76°

Observation Angle 1.05° 1.05°

Retroreflectivity(mcd/m2/lx) 250 175

Skid ResistanceThe surface of PL5000 provides excellent skid resistance.

When tested according to the procedures specified in ASTM-E-303 it exhibits an initial minimum skid resistance value of 45 BPN.Performance LifeThe performance life of pavement markings will depend on the following:• Traffic conditions• Snow removal practices• Pavement surfaces• Application techniquesIt is recommended that each customer thoroughly evaluate PLYON pavement marking tapes under the conditions in the specified location.

While experience has shown that when properly applied, these materials are highly effective traffic control devices, PLYON Technologies makes no generalized performance claims.Standard Dimension :● Standard length : 33m , 50m● Standard width : 10cm, 15cm, 20cm, 40cm, 45cm; or according to customer’s requirements.Application Methods: Inlay and overlay; Coated with quantity can be 1kg per every 5m²of road tape on new roads.

Actual amount depends on the situation of roads.Shelf life: 12 months in the first package under the condition of 23℃×65%RH. Important notice:The information, data and other statements are based on our testing results, the user should determine the suitability of the product for its intended use.
