Ratchet Pullers/ Mini Ratchet Puller - zb

wire grip/Cable Wire Grip/ Cable Grip/Aerial Bundle Conductor Clamps/ Wire Pulling Grips/Haven Grip/PULL GRIPS/Come Along Clamp/Automatic Clamps
As a Directions for manufacturer, wholesale and retail for all kinds of grips.:Aluminium conductor cable grips, Aluminium insulated conductor grips, automatic earth wire grips, iron grips,etc.

Aluminium conductor cable grips
Application: steel-cored aluminium strand wire, communication cable, copper wire, aluminium wire.
Product No. Applicable conducting wire(LGJ) Rated load (Kg) Applicable wire diameter(mm) Weight (kg)
LSJ-1 25-70 1000 6-14 1.05
LSJ -2 95-120 1500 13-18 1.40
LSJ -3 150-240 2500 17-24 2.9
LSJ -4 300-400 4000 25-37 4.0
LSJ -5 500-630 5000 30-40 6.7
Aluminium insulated conductor grips
Application: insulated conductor, bare copper wire, bare aluminium wire.
Product No. Applicable conducting wire(LGJ) Rated load (Kg) Applicable wire diameter(mm) Weight (kg)
SJKL-1 25-70 1000 Φ13.8-Φ17.8 1.55
SJKL-2 95-120 1500 Φ19.6-Φ21 2.4
SJKL-3 150-240 2500 Φ22.6-Φ26.4 3.6
SJKL-4 300-400 2500 Φ27.4-Φ29.8 5.4
Earth wire grips
Application: used for OPGW gripping..
Product No. Applicable range (mm) Rated load (Kg) Jaw shape Weight (kg)
SKG-1 Φ11.7-Φ17 2500 round 5.1

Application: used for ground wire (steel strand or aluminium steel stranded cable) construction.

Product No. Applicable conducting wire(GJ) Rated load (Kg) Max. applicable diameter(mm) Weight (kg)
SSE-1 GJ25 1000 9.5 2.5
SSE-2 GJ35 1000 9.5 2.5
SSE-3 GJ50 1500 10 3.5
SSE-4 GJ70 2000 12.5 5.0
SSE-5 GJ100 3000 14 5.0
All-universal grips:
Application: steel rope, steel strand, copper wire, insulated wire.
Product No Applicable wire diameter(mm) Rated load (Kg) Weight (kg)
SD-1000 2.6-15 1000 0.7
SD-2000 4-22 2000 1.5
SD-3000 16-32 3000 2.6
