QTJ6-20 block making machine

Main Technique Capacity and Parameter1.Four-bar guidance ensure the accurate action of pressure head and mould.2.The body of machine produced by casting of high precision ,intensity and special welding material, it features by high rigidity,good resistance to vibration and long service life.3.Electrical system using PLC controller with data entry devices export control system,including security logic control and fault diagnosis system.4.Vibrating table weth press makes blocks.

To-and-fro guiding feeder feeds the material. It is of short moulding cycle and high production efficiency.

The brick is of high instensity and accurate dimension.5.Using electromechanical integration technology, make sure the equipment running stably and low rate of waste.6.By changing mould, this machine can produce every sort of blocks such as hollow block, kerbstone, pavior brick, grassed brick and slope block.

It can produce colour pavior blocks with special device.Technical ParameterMoulding Number Moulding Cycle Capacity Power Gross Weight Overall Dimension Brace Dimension

390×190×1906block/mould 8640block/class About 20second 69120block/class 19.55kw 6T 3950×1900×2850mm 850×640×40mm

240×115×9015block/mould21600block/class

240×115×5330 block/mould45000block/class
