Pyramid anchor

pyramidal anchor Size: 25#-1000# Pyramid shaped,one piece Cast iron, permanent mooring anchor Fresh or salt water use Works well in a hard rocky or sandy bottom. Work well in tidal waters as the attached chain does not tend to wrap around the anchor shaft which is possible in an improperly set mushroom anchor.

The Pyramid shaped, one piece, cast iron, permanent mooring anchor is for fresh and salt water use. Pyramid Anchors work well in a hard, rocky or sandy bottom. This anchor works well in tidal waters, because the attached chain does not tend to wrap around the short anchor shaft.

Mooring will rapidly set itself by presenting a digging edge to penetrate the bottom. The short shank allows mooring in more shallow water with less chain wrap-up and potential hull damage. The large diameter eye is designed to accommodate a proper size shackle and chain for recommended mooring weights.

Boat Length Pyramid Anchor Weight Up to 10 ft 25 lbs 14-16 75 lbs 16-18 100 lbs 18-20 150 lbs 20-24 200 lbs 25-29 250 lbs 30-32 300 lbs
