Pulmonary function tester

Pulmonary function tester Model:ZJ15-System-7 Cat.No:W77255

Pulmonary Function Tester System-7-type 1. Use of platinum - rhodium alloy material of the hot wire type flow sensor Flow measuring range: 0-16L / S Volume Range: 0-9.999L Flow Accuracy: ± 3% of reading value or ± 0.01 L / S Disinfection method: Neutral disinfectant disinfection or UV disinfection 2.

Power requirements Rated Voltage: 110V-240V, 50Hz Output Power: 200VA 3.

Test Project number FVC (Forced Vital Capacity); 36 parameters (including the 2 curve) repeated testing, selection optimum print VC (vital capacity); nine parameters (including a curve) repeated testing, selection optimum print MVV (maximal voluntary ventilation per minute); 4 arguments (including a curve) MV (minute ventilation); three parameters (including a curve) Pulmonary function, the expansion of drug testing and bronchial provocation test, etc.

Test results and charts detail-rich (with COPD diagnostic imaging diagnostic imaging and Wada star-shaped figure) 4. There are four kinds of ad hoc reporting formats to choose from bull; a standard format, the report size A 4, B 5 2 kinds bull; At the same time free to edit the format 5.

Ad hoc formulas have predictive value for the options Is expected to provide a variety of formulas, while free to edit the formula 6.

Using the latest technology techniques, materials, new design and manufacturing bull; 17-inch color LCD display, showing a clear, simple operation bull; display the standard flow-volume loop; test prompted a warning tone and bar graph and show the time breathing gas, the operation is more simple; graphics are Overlay function, selection optimum display and printing bull; Fully automatic determination of the working environment of temperature, humidity and pressure; enter the FRC values, automatically calculated RV and TLC bull; Using the Japanese Respiratory Society on pulmonary function in the precision instrument management guidance and the United States (ATS) quality control bull; Operating System: English Windows XP; an unlimited number of full test report is stored bull; Lung age, introduced into the pulmonary function test parameters, making testing and research better bull; Ultra-high-speed color inkjet or monochrome laser printers; reported size A 4, B 5 2 kinds bull; Data Transfer: Adoption of the RS-232C interface with the computer connection, and is equipped with an external MO memory (650M) bull; using GOLD (2003 edition) on COPD, stage of disease classification; disease more scientific analysis bull; with use of disposable mouth pieces of anti-bacterial filter to prevent cross-infection technologies, make the test more secure 7.

Quality assurance: ISO9001, ISO13485 8. Extensions: closed volume, determination of residual gas and dispersion 9. Additional Accessories bull; 2 Masusada standard tube bull; trolley 10.

Configuration options: Pulmonary Function Testing Instrument System-7 standard and pulmonary function tester System-7 Simple nbsp; Pulmonary function tester Model:ZJ15-System-7
