Professional infrared thermal imager with 160x120pxls resolution

W1307 handheld infrared really innovative thermal imager model for high performance, more flexibility and easy to use.

Electrical installers, tradesperson, project developments person but also thermal or mechanical technician can using this new technologies in order to solve their maintenance problem and, in more cases, obtain a valid help on the troubleshooting and preventive analysis of problem.

The model is built with a wide 3½" LCD colour display and a laser pointer for a great accuracy during the use of meter. HT1160, thanks to a 160x120pxls better resolution, permits a really good visualization of each saved thermal image.

With internal OSD function the selectable languages, the meter parameters setting and the analysis of measurement results are completely easy to use for the operator. The thermal pictures can be saved in external SD flash card fitted inside meters with a capacity up to 1000 pictures.

The USB port permits to transfer the thermal pictures to PC also by using dedicated Windows software.

Typical applications of HT1160 thermal imager are Predictive and Preventative Maintenance Plumbing and Electrical Research and Development HVAC + refrigeration troubleshooting Vehicle Maintenance General Industrial/Domestic STANDARD CE mark FUNCTION Real time image and temperature measurement display Readout in °C, °F, °K High output resolution (160x120pxls) Wide colour LCD display 4 display palette available Class 2 laser pointer Automatic/Manual level and contrast regulation Emissivity selectable values Moveable internal selectable cursor USB port Interface for external SD flash card Low battery indication ACCESSORIES Included accessories HT1160 thermal imager Tip for protection lens Li-ION rechargeable battery AC external adapter USB cable SD flash card SD flash reader with USB cable Users manual on CD-ROM ThermoView HT1160 PC Windows software Full report writer software Rubber protection holster Wrist strap Carrying case For more details ,please contact:Porry Wang International Dept.

Manager Midwest Group nbsp; Email:&nbsp Midwest, No.1, 3rd. Street, Shangdi, Haidian, Beijing, China, 100085 nbsp; ext. 249
