Professional Speaker—Line Array series

FA-8-2A 3-way Bi-amp Line Array Loudspeake System Features: 3-way small line array system high efficiency energy output far coverage professional flying setting,safe and reliable fast install,waterproof and resist hot Description: FA-8-2A have douole 8"LF unit,double 5.25"airtight MF,a 2"compress system use advanced branching map technique,made MF and HF output the same quantity SPL.Sub-thin enclosure,the vertical point is only 12°(single enclosure),the sound deliver more long,when the multienclosure compact arrange together,the wave interfere between the enclosure can be reduced HF have no-power crossover network,the LF need processor to deal with divide frequency point.

SYSTEM : frequency rersponse:100Hz-18k Hz(±3dB) sensitivity:MF/HF 110db,LF 95dB SPL(1) Nominal lmpedance:MF/HF 8ohms,LF 8ohms Power Rating:MF/HF 200 watts (rms),500 watts(program),1000watts(peak) LF 350watt(rms),700 watts(program), 1400watts(peak) Nominal Dispersion:100 °horizontal,6°vertical Nominal Frequency:MF/HF 2 k Hz Mf/lf 350Hz Recommended High Pass Filter:high pass=>80Hz,24dB/octave DRIVERS: Low Frequency(neodymium magnet):2x8(in)200mm dia,75mm(3in)voice coil dia Mid Frequency(neodymium magnet):2x5.25(in)170mm voice coil dia,44mm(1.73in)throat dia High Frequency(neodymium magnet):2x2(in)44mm voice coil dia,23mm(1in)throat dia PHYSICAL : Enclosure Construction: 15mm birch plywood with structured Finish: Wear-resistant textured black paint Grille: Powder coated Derforated steel,foam backed Suspension Hardware:Proprietary BOB rigging system Input Connectors: Speakon NL4x2 Dimensions: 258mmx566mmx353mm Net Weight: 17g
