Pressure Control Switch is a Pressure Switches product. Key specs — Origin: China (Mainland).
Product Description
Model No.:SKD-1 Product Origin:China Brand Name:Yaoda Price Terms:FOB Payment Terms:T/T Certification:CE, TUV Description:Features:1) Rated voltage: 220V - 240V 110V - 115V2) Max. current: 10A3) Frequency: 50 - 60Hz4) Max. power: 1.1kW -2.2kW5) Starting pressure to choose: 1.5 bar / 2.2 bar6) Max. working pressure: 10 bar7) Protection grade: IP658) Joint screw: 1"9) Max. operating temperature: 60oC10) Coverage: as a completely new device, it can guarantee the optimum control of electric pumps used in a plumping systems.
Being an intelligent mix of hydraulic and electronic engineering. The control maintains both pressure and flow and controls the operation of the pump automatically. It needs no pressure tank as in the traditional systems. There are no plenum chambers to recharge an no irritating variation in pressure and in flow at the point of use.
No adjustment or maintenance is required, it is absolutely dependable durable and simple to install11) Function: the starting operation archived. The unit is programmed to perform all the pump control operations automatically.
When particular operational breakdowns occur, such as water failure, obstruction of the suction pipe, etc., the unit recognizes the breakdown and red LED failure lights up, at the same time a stop signal is sent to the pump to prevent damages caused by its working in the absence of water.
Rectification of the failures that have caused the blockage, allows the system to be restarted by pressing the reset button
