Listing ID#10223010
ModelCS15XX(FFL)
CategoryMachinery
Quick answer
Power Stacker CS15XX(FFL) is a Machinery product. Key specs — Brand: Cheuklift; Origin: CHINA.
Product Description
| Identification | 1.2 | Manufacturer’stypedesignation | CS1529(FFL) | CS1532 | CS1536(FFL) | CS1540 | |
| 1.3 | Drive:electric(batteryormains),diesel,petrol,fuelgas,manual | electric | electric | electric | electric | ||
| 1.4 | Typeofoperation:hand,pedestrian,standing,seated,order-picker | Pedestrian | Pedestrian | Pedestrian | Pedestrian | ||
| 1.5 | LoadCapacity/ratedload | Q(t) | 1.5 | 1.5 | 1.5 | 1.5 | |
| 1.6 | Loadcenterdistance | Cmm | 600 | 600 | 600 | 600 | |
| 1.8 | Loaddistance,centreofdriveaxletofork | Xmm | 765 | 765 | 765 | 765 | |
| 1.9 | Wheelbase | ymm | 1367 | 1367 | 1367 | 1367 | |
| Weights | 2.1 | ServiceWeight | Kg | 1025 | 1035 | 1055 | 1085 |
| 2.2 | Axleloading,ladenfront/rear | Kg | 1130/1395 | 1135/1400 | 1145/1410 | 1150/1435 | |
| 2.3 | Axleloadings,unladenfront/rear | Kg | 700/325 | 700/335 | 700/335 | 700/385 | |
| Wheels,Chassis | 3.1 | Tyres:solidrubber,superelastic,pneumatic,polyurethane) | polyurethane | polyurethane | polyurethane | polyurethane | |
| 3.2 | Tyresize,front | 230x75 | 230x75 | 230x75 | 230x75 | ||
| 3.3 | Tyresize,rear | 80x701) | 80x701) | 80x701) | 80x701) | ||
| 3.4 | Additionalwheels(dimensions) | 124x60 | 124x60 | 124x60 | 124x60 | ||
| 3.5 | Wheels,numberfront/rear(x=drivenwheels) | 1x+2/4 | 1x+2/4 | 1x+2/4 | 1x+2/4 | ||
| 3.6 | Trackwidth,front | b10(mm) | 570 | 570 | 570 | 570 | |
| 3.7 | Trackwidth,rear | b11(mm) | 395 | 395 | 395 | 395 |
