Portable Electrical Water Level Meter

XP85 Portable Electrical Water Level Meter
Applied geology, mining, hydrological and other departments of the hydrological observation

holes, geological drilling, wells, dams and rivers, lakes, sea, direct measurement of the

difference between the final calculation of the final outcome of the reading, to replace

the commonly used test string, measured clock , wires, multimeter, etc. A simple

measurement of water behind the original method.

From the survey line, probe, water level detector, roll wheels, frame, conductive bodies,

handles, leather backpacks, whose main characteristic is small size, light weight,

inexpensive and easy to carry.

Features:
1 The maximum measurement depth: 100m
2 the maximum measurement error: ≤ ± 0.1% FS (maximum ± 0.1
m/100m), reached the international ISO standards under three water level accuracy.
3 probe diameter: 14mm, probe sensitive area ≤ ± 5mm.
4Repeat accuracy: ≤ ± 10mm.
5 measuring line technical conditions: OD 2.0,7 / 0.25 galvanized steel core, high density

polyethylene insulation, broken pull ≥ 25 kgf.
6water level detector sensitivity: Geodetic resistance ≥ 500KΩ.
7water level detector power: ≤ 15mA.
8water level detector power: 6F22, 9V laminated battery.
9use of the environment: -20 °C ~ +40 °C, relative humidity 85%.
Dimensions (mm): 330x86x220
Probe: Φ14
Weight: 1.9 (kg)
