Pocket Video Recorder

Features: 1) The kit includes one MPEG4 DVR and one camera both built in 2.4GHz wireless modules. The effective wireless transmission range of audio/video signal up to 50M in open area. 2) The camera builds in IR LED whose effective lighting distance is around 5m. The video image is distinguishable even at dark place.

3) The portable DVR builds in 2.5 color TFT-LCD panel, speaker, and 4 x AA battery power supply, there is no limitation for the place you can see the video and hear the voice wireless transmitted from the camera 4) The DVR supports NTSC or PAL video system, and auto detects video loss, AV line in or 4 channels RF input source is selectable.

5) The DVR builds in MPEG4-SP video and G.726 audio codec. It supports 1 channel video and 1 channel audio record and playback operation. For 128 MB CF card, the record time is about 40 minutes at middle quality for NTSC: x 240 and PAL: x 280. 6) Audio/Video data are recorded directly on the compact flash card with FAT16 file system and ASF file format.

You can backup the data to a PC, and playback those ASF files with popular media players. 7) Recording date and time are video overlay with video images in ASF files 8) The DVR supports: manual, motion detection, and schedule recording mode with independent video size, quality, and frame rate set up.

9) For motion detection, multiple detection blocks and appropriate motion trigger level can be set up.

Specifications: 1) Frequency: 2.4GHz (4-ch) (2.414, 2.432, 2.450, 2.468)GHz 2) Shoot power: 10mW 3) Shoot distance: 50m 4) Pick-up device: 1/4 Panasonic CCD image sensor 5) Min illumination: 0.5Lux (F1.2, 5600ºK) 6) Horizontal resolution: 420TVL 7) S/N ratio: >52dB 8) AGC: On 9) Auto white balance: auto 10) Power supply: DC12V ± 1V 11) Current consumption: 95mA 12) Operation temperature: -20oC ~ +50oC 13) Lens: pinhole / screw / button 14) Dimensions: 33 x 25 x 23mm 15) Weight: 22 / 26 / 26g
