Listing ID#10110986
ModelRB77C
CategoryAir Conditioning Systems
Pneumatic BreakerRB77C
Specifications
- Origin
- China (Mainland)
Quick answer
Pneumatic BreakerRB77C is a Air Conditioning Systems product. Key specs — Origin: China (Mainland).
Product Description
My company has product patent right for this model. Instruction
B77C Jack hammer is a ideal tool that break up concrete and other solid object in the road construction and has characteristic of simple structure,high efficiency and handy use . As long as fix a drill shank, turn on air source, then working.
SpecificationWeight | 39kg |
|---|---|
Length | 763mm |
Rammer dia | 57mm |
Rammer stroke | 189mm |
Air pressure | 0.63Mpa |
Impact frequency | 18.3Hz |
Air consumption | 34L/s |
Air pipe inner dia | 19mm(3/4”) |
Lubrication capacity | 30ml |
Bit shank size | 32*152mm |
