Platinum based silicone rubber

Platinum based silicone rubber application HY-988 is a kind of addition cure high temperature resistance organic molding silicone rubber.It's liquid with moderate viscosity and can be poured and mold made out of the silicone and curing agent,which with high temperature up to 250-300°C,has dimension stability,low linear shrinkage.It’s a two-component material with mixing ratio of 10:1,and it’s used for soft mold making,etc.&nbsp 988# Platinum based silicone rubber TDS Model

Color

Mixing ratio (%)

Pot life (mins)

Demould time ( min)

Hardness ( A0 )

Tensile-strength (Mpa)

Tear-strength (kN/m)

Viscosity (mPas)

Shrinkage rate (%)

Elongation (%)

988#

Transparent

10:1

30

10

42

≥ 4.2

≥ 1.6

56000

≤0.1%

400%

&nbsp &nbsp &nbsp &nbsp Platinum based silicone rubber Features:&nbsp Silicone rubber will not release low molecule under the condition of crosslinking,so the volume will not vary,linear shrinkage will less than 0.1%;it does not subject to the thickness of the products, and can be cured deeply;it with high tensile and tear strength and anti-yellowy under high temperature of 200°C.

Platinum based silicone rubber Applications: It's applicable to make mold,development and design for mobile model, exquisite odel,lead-zinc alloy crafts and the products with low shrinkage. Any questions of Platinum based silicone ,please feel free to contact Mr. Jensen

86+13410935459 Mail: hyt(at)szrl.net
