Plastic Structured Packing

specifications

material

mesh

peak height

dip

surface area

void

density

Head

mm

degree

m 2 / m 3

m 3 / m 3

kg / m 3

500 type (BX)

polypropylene / polypropylene acrylic

40

6.3

30

450

0.85

120

624-type

polypropylene / nylon

40

4.5

45

624

0.96

450-type

polypropylene / nylon

40

6.2

30

450

0.97

models

number of theoretical plates

surface area

void

pressure drop

accumulation of weight

maximum F factor

fluid load

block / m 2

m 2 / m 3

m 3 / m 3

Mpa / m

kg / m 3

m / s (kg / m 3 ) 0.5

m 3 / m 2 . Hr

SB-125Y

1-2

125

0.985

2 × 10-4

37.5

3

0.20-100

SB-250Y

2-2.5

250

0.97

3 × 10-4

75

2.6

0.20-100

SB-350Y

3.5-4

350

0.95

2 × 10-4

105

2

0.20-100

SB-500Y

4-4.5

500

0.93

3 × 10-4

150

1.8

0.20-100

SB-125Y

0.8-1.9

125

0.985

1.4 × 10-4

37.5

3.5

0.20-100

SB-250X

1.5-2

250

0.97

1.8 × 10-4

75

2.8

0.20-100

SB-350

2.3-2.8

350

0.985

1.3 × 10-4

105

2.2

0.20-100

SB-500X

2.8-3.2

500

0.93

1.8 × 10-4

150

2

0.20-100
