Plastic Granulator

SJLZ Serial Plastic Granulator Unit

Granulation with PVC powder lot is one production means generally adopted by plastic manufacturers, aiming at discharging gas and increasing plasticizing effect. The unit matched with corresponding twin-screw or single-screw extruder, con process hard and soft PVC granular materials in high efficiency and quality. Among the granulator unit series, the waste film reclaiming granulator researched and developed by us through referring foreign advanced models is excellent in granulation quality and high in output, thus is the ideal reclaiming granulator unit for film manufacturers.

PVC granulator

machine:

model: SJ-120/20 single screw extruder , motor power: 55Kw, heating power: 35Kw.

cutting pellet head: 1set

c pelletizing car,1 set ,power 2.2Kw

d,air carry machine,1 set, power 3kw

e, collecting bin 1 set

f. productivity:7 tons / day

price: 190,000 yuan

A, PE recycled material granulator crusher unit

1),main machine:

A, Model: SJSP 75 building block-style parallel twin-screw extruder

B, main motor: power 75Kw, frequency contral

C, heating power: 35Kw

D, Feeder: power 1.5Kw

2,cold-cutting pellet head 1set

3,4-meter-long stainless steel sink 1set

4,air blow drying machine, power 1. 5Kw

5,500 style high-speed granulator Power 5.5Kw, electromagnetic speed regulation.

price: 280,000 yuan
