Photovoltaic Solar Electric System(600VA--6KVA )
Specifications
- Brand
- BAYKEE
- Origin
- guangdong in China
- Price Term
- FOB
Photovoltaic Solar Electric System(600VA--6KVA ) is a Electrical Equipment & Supplies product. Key specs — Brand: BAYKEE; Origin: guangdong in China; Price Term: FOB.
Product Description
Certification:CQC
Solar Power System
Capacity range ：
600VA , 1KVA, 1.2VA, 1.5VA, 2KVA, 3KVA 4KVA 6KVA
Applications
Mainly used with solar or wind system, load type: Fan, TV, PC, lamp etc.
Features & Benefits:
Pure sine wave output (with battery or main input)
With AVR option
Generator compatible
High efficiency and stabilization
Working mode: ups or inverter
Can use different type of battery such as SLA; maintenance battery
Soft start without main input
Overload, short-circuit, battery low; over temperature etc protection
Technical Specifications
Solar Power System | ||||||||||
Model | BKH506 | BKH510 | BKH512 | BKH515 | BKH520 | BKH530 | BKH540 | BKH560 | ||
VA | 600VA | 1000VA | 1200VA | 1500VA | 2000VA | 3000VA | 4000VA | 6000VA | ||
Watt | 420W | 700W | 840W | 1050W | 1400W | 2000W | 2600W | 4100W | ||
Input | ||||||||||
Phase | 1phase+N | |||||||||
Voltage | 180V~260±5V (UPS working) | |||||||||
165V~285±5V (Inverter working) | ||||||||||
Frequency | 50Hz/60Hz±5% | |||||||||
output | ||||||||||
Voltage | 200V/220V/230V/240V ± 10% | |||||||||
Waveform | Pure Sine Wave | |||||||||
Frequency | 50Hz/60Hz± 1%( mains abnormal) | |||||||||
Crest factor | 3:1 | |||||||||
Overload | >110% for 10min; >120% for 1min; >130% for 10ms | |||||||||
Short Circuit | >250% Load (Several ms) | |||||||||
Battery | ||||||||||
DC voltage | 24VDC | 48VDC | 72VDC | 96VDC | ||||||
Charge Current | 8~20Amp( Presettable ) | |||||||||
Others | ||||||||||
Protection | Short circuit, Battery Low, Overload, over temperature | |||||||||
Noise | <45db (1 Meter) | |||||||||
Temperature | 0~ 45℃ | |||||||||
Humidity | 0~90%(Non-condensing) | |||||||||
Dimension(mm) | 245×315×130 | 280×350×150 | 380×450×220 | |||||||
Weight (kg) | ||||||||||
