Paper board insulating plate press
Specifications
- Brand
- 1997
- Origin
- China (Mainland)
- Price Term
- FOB
Paper board insulating plate press is a Non-Metallic Mineral Deposits product. Key specs — Brand: 1997; Origin: China (Mainland); Price Term: FOB.
Product Description
BF series insulating plate presses are suitable for producing multi-layer insulating copper-foil-covered plates in electronic industry.
BJ for multi-layer insulating plates in insulator field.
BB for multi-layer insulators in transformer area.
The insulating plate presses are suitable to make multi-layer glass cloth, cardboard and mica insulating the compacting process can be realized automatically.Usually the insulating plate press consists of hot press, loading and unloading device, chain type conveyor etc.
Specifications:
No. | Description | BF-1500 | BJ-1600 | BJ-2600 | BB-2400 |
1 | Nominal force (KN) | 15000 | 16000 | 26000 | 24000 |
2 | Hot plate size (mm) | 1350×1250×60 | 2100×1100×70 | 2500×1300×70 | 2500×2500×80 |
3 | Hot plate pressure(MPa) | 9 | 6.9 | 8.0 | 3.8 |
4 | Layers | 20 | 13 | 15 | 5 |
5 | Interlayer space(mm) | 100 | 150 | 150 | 150 |
6 | Diameter of piston(mm) | 400 | 630 | 450 | 420 |
7 | Nos of oil cylinder | 4 | 2 | 6 | 6 |
8 | System working pressure(MPa) | 29 | 26 | 27 | 29 |
9 | Closing speed of hot press(mm/min) | ≥500 | |||
10 | Heating mode | Heat conducting oil or steam or electric heater | |||
11 | Cooling mode | Water or oil | |||
12 | Max. temperature(℃) | ≤250 | ≤160 | ≤160 | ≤250 |
