Panasonic TH-50PHD8UK

TH-50PHD8UK 50-IN HDTV PLASMA DISPLAY

Key Features 50-inch, 16:9 aspect ratio

Screen Size W x H 43.5" x 24.5"

Diag. 50" (1,269 mm)

Resolution (1,366 [W] x 768 [H])

Contrast Ratio 3000:1

Dimensions (W x H x D) 47.6" x 28.5" x 3.7"

Weight 94.8 lbs. (43.0 kg)

Color System NTSC, PAL, PAL 60, SECAM, Modified NTSC

Applicable PC Signals: XGA (Signals exceeding XGA are compressed and displayed.)

VIDEO IN/OUT (BNC): 1.0 Vp-p (75-ohms or high-impedance) (Slot-type)

S-VIDEO (Mini DIN 4-pin): Y: 1.0 Vp-p (75-ohms), C: 0.286 Vp-p (75 ohms)

AUDIO IN L/R (RCA pin jack x 2): 0.5 Vrms (high impedance)

Y/G (BNC): 1.0 Vp-p/composite (75-ohms); 0.7 Vp-p/non-composite (75 ohms)

PB, PR/CB, CR (BNC): 0.7 Vp-p (75 ohms); R/B (BNC): 0.7 Vp-p (75 ohms)

AUDIO IN L/R (RCA pin jack x 2): 0.5 Vrms (high impedance)

Mini D-sub 15-pin)

External control terminal (D-sub 9-pin), RS-232C compatible

TH50PHD8UK Product PANASONIC TH-50PHD8UK 50-IN HDTV PLASMA DISPLAY

SKU TH50PHD8UK

Manufacturer PANASONIC

Screen Size 50"

Resolution 1366 x 768

Dot Pitch Data Not Available Aspect Ratio 16:9

Contrast Ratio 3000:1

Brightness Data Not Available

Colors 3.62 Billion

View Angle 160 degrees

Dimensions 47.6" Width, 28.5" Height, 3.7" Depth

Weight 94.8 lbs

Power 120V, 50-60Hz, 440W

manufacturer warranty

Signal Input Mode DB15 PC Video Input

Inputs/Outputs 1x Composite (BNC)/S-Video Input (Shared)

1x Component Video Input (BNC)

1x DB15 PC Video Input

1x RS-232C Input (Firewire)

1x Composite Video Output (BNC)

Included Accessories Operating Instruction Book, Remote Control Transmitter (EUR7636070R), Batteries for the Remote Control Transmitter (2 × AA Size), Warranty, Fixing bands × 2, AC cord

Other NTSC, PAL, PAL60, SECAM, Modified NTSC

VGA, SVGA, XGA, SXGA, UXGA (compressed) PC signal compatibility

Built-In Video Wall Processor - set up 2x2, 3x3, or even 4x4 multi-screen plasma walls

Up to 60,000-hour panel life - MACH Panel boasts a long service life of 60,000 hours
