PVC profile window machine

Vertical Four-point Welding Machine for PVC is make up of four heads, fixed pole, active pole, machine frame, electricity control ark, etc. CNC Vertical Four-point Welding Machine for PVC head is made up of orientation heating mechanism, horizontal feeding pressing mechanism and vertical feeding pressing mechanism etc.

The left up and down heads can be opened and closed along the fixed pole. The right up and down heads can be opened and closed along the moving pole. The orientation heating mechanism can realize orientation and heating. The up and down clamp can realize the pressing. This machine is used for PVC door and window welding processing.

The four heads can work at the same time. And it enables a one-step welding for rectangle window frame and sash. It adopted PLC. It features high reliability and wide processing range. It is easy to operation. It is efficient and suitable for batch production. The operation is very easy. The rectangle window frame can be welded at one step.

It is very Vertical Four-point Welding Machine for PVC Input Voltage 220V 50Hz Input Power 10 KW Air Pressure 0.5-0.8 MPa Air consumption 200 L/min Welding Height 20-120 mm Welding Width ≤120 mm Welding Range 300×300-1800×3000 mm Overall Dimension 5000×1728×2870 mm
