PE Foaming Sheet Extrusion Line

(Width400 mm, thickness 0.3-5mm)

I,Basic equipment configurations:

1,Charging system

2,Main extruder

screw diameter 90mm

L/D ratio 50:1

Main motor: 37KW, frequency speed control

3, Main extruder and auxiliary equipment switch cabinet

4, Auxiliary equipments

1)Calibrating drum devicewater cooling and fan cooling

2)Cast-aluminium air delivery adjustable cooling air-rings

3Blade-cutting device

4Flattening bracket

5Hauling machine: niprolls, drive motors

5,Double-station rotary rolling machine

II,Technical parameter

1Sheet thickness: 0.5~3mm

2Sheet width: 400mm

3Foaming magnification: 20 times

4Output: 120-180kg/h

5Loading power: 70kw

6Assembling overall size: 30x2.6x2.6m

7Total weight of equipment: 12 Ton

III, Choice equipments according to your request

1sheet thickening machine

2Cutting off machine

IV,Assembling, adjustment and after-sell service

1Theseller send engineers to help assembling and adjusting equipments inthe buyers workshop, the buyer will be responsible for tickets cost andaccommodation

2The seller offer One-year quality guarantee forthe equipments , the buyer must operate the equipment in properway(Wearing parts and non-appropriative parts not in warranty. Such as:belts, chains, bearings, blades, etc.)

3The seller offer the buyer directions for producing sheet products and whole set of technics.

4 The seller offer long-term technique assistance and spare parts.
