PARKING SENSOR SYSTEM
Specifications
- Origin
- Guangzhou, China
- Price Term
- FOB
PARKING SENSOR SYSTEM is a Vehicle Parts & Accessories product. Key specs — Origin: Guangzhou, China; Price Term: FOB.
Product Description
All kinds of colors for sensors can be choosed freely
CE CERTIFICATE CAN BE PROVIDED FOR PARKING SENSOR
Packing details: gift box size: 25.0*18.0*6.5cm; G.W.: 0.65kg/set; 13.50kg/carton;20sets/carton; Carton size:74.5*27.5*35.5CM
The length of cable from control box to display is 6.5m; The cable of cable from control box to sensor is 2.5m;
The power cable is 1.5m
Product Introduction:
Technical specification:
1.Rated voltage:12v DC; 2.Working Range:8-15V DC; 3.Rear:0.3 to 2m; 4.Ultrasonic frequency:40KHz;
5.Working temperature:-40 to +75 degrees Celsius;
Product Features:
sensitivity ultrasonic detector;2.real-time direction and distance display on LED screen;
3.Intellectual step-by-step voice-directed alarm system;4.Safer parking operation;5.Number of sensors: 4 pcs;
6.Displayed colors in screen: Green, Yellow, Red;
7.waterproof sensors work well under severe weather and temperature condition;
| Alarm mode | |||||||||||
| 　 | Stage | Distance | Awareness | Display | Alarm sound | 　 | |||||
| 　 | 1 | >2.0m | Safe | — — | Silent | 　 | |||||
| 　 | 2 | 2.0~1.6m | Safe | 2.0~1.6 | Silent | 　 | |||||
| 　 | 3 | 1.5~1.1m | Alarm | 1.5~1.1 | Slow ring(Bi……Bi……Bi……) | 　 | |||||
| 　 | 4 | 1.0~0.7m | Alarm | 1.0~0.7 | Normal ring(Bi… Bi… Bi…) | 　 | |||||
| 　 | 5 | 0.6~0.4m | Danger | 0.6~0.4 | Fast ring(Bi, Bi, Bi) | 　 | |||||
| 　 | 6 | 0.3~0.0m | Danger | 0.3~0.0 | Continuously ring (Biiii……) | 　 | |||||
| 　 | Stage | Distance | Color | Stage | Distance | Color | 　 | ||||
| 　 | 1 | >2.0m | Extinguishing | 3 | 0.8~0.5m | Yellow | 　 | ||||
| 　 | 2 | 2.0~0.9m | Green | 4 | 0.4~0.0m | Red | 　 | ||||
