OF-550 Bench-top Optical Laser Source
Specifications
- Origin
- CHINA
OF-550 Bench-top Optical Laser Source is a Fiber Optic Equipment product. Key specs — Origin: CHINA.
Product Description
General introduction
OF-550 Bench-top Optical Laser Source is a semiconductor laser source based on intelligent micro-processing control, relying on high accuracy automatic power control (APC) and automatic temperature control (ATC) techniques. OF-550 has a high stable output and various wavelengths to meet customers’ requirement. It supports various lasers such as DFB, FP, PUMP, SLED and can be applied in components testing, and power meter calibration, etc.
Features
Large Color LCD display
High stability and reliability
Multi output and dual wavelength combining function
Specification
Module | OF-550 |
Emitter Type | FP，DFB，LED，SLED |
Operating Wavelength（nm） | 1310/1550 or can be specified |
Output Power（dBm） | ＋3dBm or can be specified |
Output Stability（dB/15min） | ±0.005 |
Output Stability （dB/8h） | ±0.05 |
Optical Output | CW，internal modulation，external modulation |
Optical Connector | FC/APC Connector |
Operating Temperature（℃） | -10~+60 |
Storage Temperature（℃） | -25~+70 |
Power Supply | AC 220V ±15％50Hz±10Hz |
Dimension（mm） | 300×260×120 |
Weight（kg） | 2.3 |
