Non-Woven Bag Making Machine
Specifications
- Brand
- HUANA
- Origin
- China
- Price Term
- FOB
Non-Woven Bag Making Machine is a Bag Making Machines product. Key specs — Brand: HUANA; Origin: China; Price Term: FOB.
Product Description
This machine equips computer orientation, photocell tracking, and man-machine interface touch screen operation; adopts high wave band ultrasonic heat-combining elements; make up of the functions with bag mouth inner folding, ribbon-through, stiletto, ultrasonic heat-combining cold-cutting etc. It’s the advanced machine to produce kinds of non-woven fabrics handle shopping bag, shoes bag, fashion t-shirt bag 15-50g. Our company also can make the given design according to the customer’s requirement of different bag sizes.
Main Technical Variables:
| Type | HNL-B600 | HNL-B700 | HNL-B800 |
| Production Speed | 20-100pcs/min | 20-100pcs/min | 20-100pcs/min |
| Bag Width | 100-800mm | 100-800mm | 100-800mm |
| Bag Length | 200-480mm | 200-580mm | 200-700mm |
| Bag-making Thickness | 40-120g | 40-120g | 40-120g |
| Power Supply | 380V/220V | 380V/220V | 380V/220V |
| Total Power | 10Kw | 12Kw | 15Kw |
| Overall Dimension (L*W*H) | 7800*1650*1800mm | 7800*1800*1800mm | 7800*1900*1800mm |
